Hydraulic Hose Assembly, Medium Pressure, Length 300 mm (02762-00203)
R 617.18
R 536.68
LOW STOCK
Part Number
02762-00203
Komatsu Genuine hydraulic hoses are a critical component of the hydraulic system. Hoses are used for fluid conveyance and are specifically engineered and tested to handle extreme pressure and temperature changes.
| Diameter-ID (mm) | 6,3 |
|---|---|
| Left Fitting Angle | Straight |
| Left Fitting Type | Face Seal |
| Length (inch) | 11,81 |
| Length (mm) | 300 |
| Pressure Rating-Mpa | 3 |
| Right Fitting Angle | Straight |
| Model Type | D155AX-5, D65EX-17, D65EX-18, D65PX-17, D65PX-18, D65WX-16, D65WX-17, D65WX-18, PC138US-10, PC138US-11, D65EX-16, D65PX-16, WA150-3, HD785-7, HM400-2, PC138US-8, WA1200-6, WA800-3 |
| Right Fitting Type | Face Seal |
| Temperature Rating (Celsius) | -40?+120 |
| Length [inch] | 11.81 |
| Length [mm] | 300 |
