Hydraulic Hose Assembly, Medium Pressure, Length 1200 mm (02763-00612)
R 3,609.00
R 3,138.26
No stock available online.
Please contact your nearest branch to place a back order.
Part Number
02763-00612
Komatsu Genuine hydraulic hoses are a critical component of the hydraulic system. Hoses are used for fluid conveyance and are specifically engineered and tested to handle extreme pressure and temperature changes.
| Diameter-ID (mm) | 19,1 |
|---|---|
| Left Fitting Angle | Straight |
| Left Fitting Type | Face Seal |
| Length (inch) | 47,24 |
| Length (mm) | 1200 |
| Pressure Rating-Mpa | 3 |
| Right Fitting Angle | 90 |
| Model Type | HM400-5, PC350-7, HM400-3, PC2000-8, PC300-7, PC300LC-7, PC350LC-7, PC600-8, PC700LC-8 |
| Right Fitting Type | Face Seal |
| Temperature Rating (Celsius) | -40?+120 |
| Length [inch] | 47.24 |
| Length [mm] | 1200 |
