Hydraulic Hose Assembly, High Pressure, Length 500 mm (02766-00305)
R 1,692.90
R 1,472.09
No stock available online.
Please contact your nearest branch to place a back order.
Part Number
02766-00305
Komatsu Genuine hydraulic hoses are a critical component of the hydraulic system. Hoses are used for fluid conveyance and are specifically engineered and tested to handle extreme pressure and temperature changes.
| Diameter-ID (mm) | 9,5 |
|---|---|
| Left Fitting Angle | Straight |
| Left Fitting Type | Face Seal |
| Length (inch) | 19,69 |
| Length (mm) | 500 |
| Pressure Rating-Mpa | 20,5 |
| Right Fitting Angle | 90 |
| Model Type | HM300-3, HM300-5, WA480-5, WA800-8, GD535-5, HM400-1, HM400-2, WA380-5, WA430-5 |
| Right Fitting Type | Face Seal |
| Temperature Rating (Celsius) | -40?+120 |
| Length [inch] | 19.69 |
| Length [mm] | 500 |
