Hydraulic Hose Assembly, High Pressure, Length 550 mm (02766-004A5)
R 1,489.07
R 1,294.84
No stock available online.
Please contact your nearest branch to place a back order.
Part Number
02766-004A5
Komatsu Genuine hydraulic hoses are a critical component of the hydraulic system. Hoses are used for fluid conveyance and are specifically engineered and tested to handle extreme pressure and temperature changes.
| Diameter-ID (mm) | 12,7 |
|---|---|
| Left Fitting Angle | Straight |
| Left Fitting Type | Face Seal |
| Length (inch) | 21,65 |
| Length (mm) | 550 |
| Pressure Rating-Mpa | 20,5 |
| Right Fitting Angle | 90 |
| Model Type | HD785-8, HM300-3, HM300-5, HM400-5, PC450LC-10, PC450LC-11, D85EX-15, D85PX-15, HD465-7, HD785-7, HM400-1, HM400-2, HM400-3, WA1200-6, WA380-6, WA800-3 |
| Right Fitting Type | Face Seal |
| Temperature Rating (Celsius) | -40?+120 |
| Length [inch] | 21.65 |
| Length [mm] | 550 |
